Every capability shares this vocabulary. Each term is defined once, in the table for the area that owns it - skim the tables, then follow the links for the full guides.

entity-relationship style diagram. Left: Agent emits Traces (with child Spans and Tool calls), Traces group into Sessions. Middle: Patterns and LLM judge scorers read Traces/Sessions and raise Signals. Right: Datasets (Questions + criteria) drive Evaluation Runs producing Results with ratings. Bottom: Prompts and Tool Schemas registries receive evidence from Signals and Results. — How the core objects relate: traces group into sessions; scorers raise signals; datasets drive eval runs; findings become validated registry proposals.

Tracing

Term	Meaning
Trace	One agent interaction: a root record with input, output, latency, model, tokens, and tool calls. See Tracing.
Span	One step inside a trace - a graph node, LLM call, tool execution, or retrieval - linked by `spanId`/`parentSpanId` into a tree. The trace dialog’s Timeline and Graph views render this tree. See Span kinds.
Session	The conversation a trace belongs to: every trace sharing a `session_id`. Sessions get their own Observe view, turn counts, a conversation-level coherence score, and session-scoped judging once the conversation goes idle. See Sessions.
Tool call	A recorded tool invocation (name, arguments, result, success flag). Feeds tool-quality metrics, the Tool-failure check, and trajectory matching.
Agent	The named producer of traces. Auto-registered on first ingest; carries a monitoring profile and a healthy rate in the Agents tab.

Monitoring

Term	Meaning
Scorer	Anything that can pass judgment on traffic, managed from the one Scorers tab: patterns, LLM judge scorers, and custom scorers. All opt-in - nothing is judged until a scorer is enabled.
Pattern	A deterministic scorer: one of the six shipped templates (secrets, PII, prompt-injection echo, profanity, refusal / non-answer, malformed JSON) or a rule you author from phrase, regex, and semantic (LLM-judged) conditions. Polarity is `failure` (raises an issue) or `proper` (an informational match, counted as neither a failure nor a healthy run).
Operational outcome	NOT a scorer: a fact the trace itself recorded - an error, a failed tool call, an empty response. Always classified into the KPI failure metrics, never raises a triage signal, nothing to enable.
Signal	One deduped finding: repeated matches of the same scorer for the same agent accumulate on one row (occurrence count, last-seen) instead of flooding the list. Triage with statuses, archive or resolve what’s done - a re-firing archived or resolved signal reopens automatically.
LLM judge scorer	ONE judge entity usable everywhere: a rubric (criteria + judge prompt + judge model + tool-context level), an offline profile (dataset-run grading - the scorer’s id IS the `scorer_id` runs take), and an optional online profile whose single Score live traffic switch is the only gate (per trace, or per session once a conversation goes idle). Low live scores raise signals. (Its halves are “evaluation settings” and “online evaluator” in the legacy SDK/API surfaces - same entity, older names.)
Custom scorer	Your own logic per sampled trace: an external HTTP endpoint returning a verdict, or a code scorer - a Python or JavaScript `handler()` you write, run in-engine, scoring 0-1. See Custom scorers. (“Custom evaluator” in the SDK/API.)
User feedback	An end user’s thumbs up/down forwarded from your app (`client.feedback.report`) - human ground truth attached to the trace: raises a triage signal on a downvote, drives the Downvote rate KPI, and feeds judge calibration. Not a scorer; nothing to configure. See User feedback.
Topic	Automatic clustering of traffic by subject: the Topics tab and the Overview topic map, and the traffic side of dataset coverage.
Outcome	A real-world result you report back (`client.outcomes.report`) - refund issued, ticket reopened - used to compare judge verdicts against reality. See Outcomes.
Judge calibration	Overview’s scoreboard for the judges themselves: how often automated verdicts agreed with recorded reality (reported outcomes, user votes, human re-scores). See Outcomes.
Judge tuning	Rewriting an online judge’s grading criteria from its recorded disagreements with reality - validated by exact re-judging (fixes the cases it got wrong, preserves a control set it got right) before a human publishes.
Alert rule	A threshold on an aggregate - failure rate, p95 latency, estimated cost, judge failures, trace count - over a sliding window, paged to Slack, Teams, PagerDuty, email, or a webhook with a firing/resolved lifecycle (Alert rules). Distinct from a scorer’s per-verdict alert threshold and from an automation rule’s per-trace routing.
Model comparison	An Overview card aggregating quality, cost, and latency per model from real traffic - which model is actually earning its bill. See Model comparison.

Evaluation

Term	Meaning
Dataset	A versioned, reusable set of test cases plus scoring configuration (criteria, metrics, code scorers, CI settings). Runs snapshot the dataset version they used. See Build a dataset; cases can also be curated from production traces.
Question	One test case: `query`, optional `expectedResults` (the reference answer), optional per-case `judgeGuideline`, optional expected trajectory, optional smoke-test variants (LLM-paraphrased rewordings to catch phrasing brittleness).
Evaluator config	Legacy name for an LLM judge scorer’s rubric + offline profile (the evaluation settings record). Not a separate entity since the unification - managed from the Scorers tab, and its id is the scorer’s id.
Evaluation run	One execution of a dataset against an agent: every output, its scores, the locked dataset version, and the subject description. Statuses: `in_progress` → `completed` or `failed`.
Judge rating	The LLM judge’s 0-10 score with a written justification. When a result links its trace, the judge also sees the execution trajectory - tools called, order, failures - not just the final text.
Similarity metrics	Optional per-dataset scorers against `expectedResults`: vector (cosine) similarity, Jaccard token overlap, BLEU, ROUGE-L.
Code scorer	A JavaScript function run in-engine against each result - deterministic checks (format, keywords, tool behavior) that need no LLM. See Code scorers.
Trajectory match	A deterministic pass/fail comparing the tool calls a linked trace actually made against the case’s `expectedTrajectory` (a `tools` list plus a `mode`): `strict` (same calls, same order), `unordered` (same calls, any order), `superset` (all expected present, extras allowed), `subset` (nothing unexpected, missing allowed).
Model portability	Replay a captured trace’s input against alternative models for a quick cost/latency/quality comparison, without touching your agent. See Model portability.
Evaluation subject	Metadata describing what was evaluated (`kind`, `displayName`, `framework`, optional `version` for version comparison).

CI/CD

Term	Meaning
Gate	The pass/fail decision for a pipeline: rating floor (`fail_under`) and/or no-regression versus a baseline run. Recorded gates land in the dashboard’s CI Gates view. See CI/CD.
Pass rate	Fraction of cases passing every threshold rule (0.0-1.0).
Threshold	A per-metric rule on the dataset (“judge rating ≥ 7”, “cosine ≥ 0.8”) counted into the pass rate.
Fail fast	Finalize the run as failed on the first threshold violation instead of waiting for remaining cases.

Insights and Improve

The old Improve tab merged into Insights, which holds three views: Suggestions, Dataset coverage, and Auto-improve (confirmed failures become an improvement report that becomes a code fix - see Auto-improve). The Prompts and Tools & MCPs registries live under the sidebar’s Manage section.

Term	Meaning
Suggestion	One queued improvement proposal in Insights → Suggestions (the improvement inbox): a background sweep notices fresh failure evidence on a prompt or tool schema, generates the proposal, runs its baseline-vs-candidate validation, and queues it with the measured verdict attached. Humans review, then publish or dismiss.
Dataset coverage	Insights → Dataset coverage: does your dataset look anything like your traffic? Joins production topics to dataset cases and reports traffic-weighted coverage, topic breadth, and risk-weighted coverage, plus a probe for whether one specific query (or a pasted list) is covered.
Prompt registry	Versioned prompts your agent pulls at runtime (`client.evaluations.prompts`), with judge-proposed, human-approved rewrites. See Prompt Management.
Tool schema registry	Versioned tool definitions with failure evidence gathered from traces and playground runs, and “Suggest improvement” proposals. See Tool schemas.
Proposal validation	Before adopting a proposed change, AgentX runs candidate-vs-current against a dataset and shows the measured difference. See Validating proposals.
